New Arrival
SKU DWS-CS-1214
Friction Stay Hinge — Casement
This friction stay hinge uses an adjustable-tension slider to hold a casement sash open at any angle rather than fixed peg positions, giving finer ventilation control. Manufactured from stainless steel track and a zinc-alloy slider block, the friction setting is factory-calibrated and field-adjustable via a single set screw.
Available Finishes
Minimum order quantity: 200 units
Technical Specifications
| Material | Stainless Steel Track, Zinc Alloy Slider |
|---|---|
| Length | 300 mm |
| Sash Weight Rating | 12 kg |
| Cycle Rating | 25,000 cycles |
| Weight | 160 g |
You May Also Need
Related products
Best Seller
DWS-CS-1201
Peg Stay Casement Window Stay — 250mm
